Split hot water system

Principle of operation

In this system, the heat collector and the hot water storage tank are separated in structure, and the installation positions of the heat collector and the hot water storage tank are flexibly placed according to the needs. Replacement heat device and electric auxiliary heating device in the hot water storage tank. The heat collector receives the sun's radiation and the temperature rises, the system control device system circulation device is activated, the heat medium is forced to circulate between the heat collector and the heat exchange device in the hot water storage tank, and the heat medium passes through the heat exchange device and the hot water storage tank The water exchanges heat to heat the water in the hot water storage tank. The hot water supply adopts the top water supply, which ensures the same pressure of cold and hot water supply, which is convenient and comfortable to use. The combination of solar energy system and conventional energy (electricity) realizes all-weather hot water supply.

System characteristics

1.The collector is separated from the hot water storage tank, which is easy to integrate with the appearance of the building.

2.The collector can be installed on the south facade of the building to solve the problem of insufficient solar installation area on the roof of high-rise buildings.

3.The collector can be installed on the roofs of buildings with various shapes, which is convenient to combine with the architectural beauty.

4.The heat collector is manufactured with advanced science and technology, with fast hot start, high efficiency, and eliminates the risk of water leakage.

5.The hot water storage tank can be flexibly placed according to user needs.

6.The hot water storage tank adopts an enamel-lined pressure-bearing water tank, which has sanitary water quality, high pressure-bearing capacity, corrosion resistance and long service life.

7.Auxiliary accessories are selected from international high-quality products, with reliable quality.

8.The system operates under double pressure, and the operation is stable.

9.Intelligent system control, high comfort.

10.System capacity can meet the needs of users for different usage.

11.Each set of independent systems can be used by users as they live, which is convenient for later property management and maintenance.
